72V 160Ah Lithium Golf Cart Battery

Our 72V 160Ah LiFePO4 Golf Cart Battery delivers cutting-edge power solutions for OEM partners and wholesale buyers. As a trusted lithium battery manufacturer, we specialize in customizable energy systems that combine durability, efficiency, and smart technology for diverse industrial and mobility applications.

Key Features

Unmatched Energy Output: 72V/160Ah configuration provides 12.288 kWh capacity, enabling up to 180 km range per charge for extended fleet operations.
Ultra-Durable Chemistry: 6,000+ cycles at 80% DoD ensure 8-10 years of service life, reducing replacement costs by 70% versus lead-acid alternatives.
Military-Grade Protection: IP67-rated enclosure with shock-resistant metal casing operates flawlessly in -20¡ãC~65¡ãC environments, ideal for outdoor logistics.
Smart Power Optimization: 32-bit BMS monitors voltage/temperature in real-time, enabling Bluetooth-enabled fleet management and fault diagnostics.

Product Description

Engineered for OEM integration, our 72V 160Ah LiFePO4 Golf Cart Battery (960x446x217mm, 88 kg) supports 250A continuous discharge for heavy-load vehicles. Proprietary thermal management eliminates external cooling needs, while modular terminals allow parallel connections for scalable power demands. The 80A fast-charging capability achieves 100% SOC in 4.5 hours, backed by ISO-certified safety protocols against overcurrent and cell imbalance.

Customizable CAN/RS485 interfaces enable seamless integration with vehicle telematics, while optional NFC tags streamline maintenance tracking. As a lithium battery manufacturer focused on OEM partnerships, we offer flexible branding and performance tuning to match specific voltage/current requirements.

How Does a 72V 160Ah Lithium Golf Cart Battery Deliver High Performance?

A 72V 160Ah lithium golf cart battery delivers high energy capacity, extended range, and superior durability using advanced LiFePO4 technology. Its long cycle life, fast charging capability, and integrated Battery Management System (BMS) ensure safe, reliable, and maintenance-free operation, making it ideal for modern electric golf carts and similar electric vehicles.

What are the technical specifications of a 72V 160Ah lithium golf cart battery?

This battery features a nominal voltage of 76.8V and a capacity of 160Ah, providing approximately 12.28 kWh of energy. It supports continuous charge and discharge currents of 30A and 160A respectively, with peak discharge currents up to 315A for 10 seconds. The battery measures about 960 x 446 x 217 mm and weighs roughly 88 kg. It is housed in a robust metal casing with an IP67 rating for dust and water resistance.

How does a 72V 160Ah lithium battery improve golf cart performance and range?

With its high energy density and capacity, this battery extends golf cart driving range to approximately 130-180 km (80-111 miles) per charge. Fast charging reduces downtime, while consistent power output throughout discharge enhances vehicle speed and torque, improving overall performance and user experience.

What advantages do LiFePO4 batteries offer over lead-acid batteries in golf carts?

LiFePO4 batteries provide up to 6 times longer cycle life (over 6000 cycles at 80% depth of discharge), faster charging, lighter weight, zero maintenance, and superior safety due to thermal stability. They eliminate acid spills and reduce environmental impact, lowering total cost of ownership.

How long is the cycle life and expected lifespan of a 72V 160Ah lithium golf cart battery?

Designed for over 6000 cycles at 80% depth of discharge, this battery can last up to 10-15 years depending on usage and maintenance, significantly outlasting traditional lead-acid alternatives.

What safety features and certifications ensure the reliability of this battery?

Equipped with a smart BMS, the battery protects against overcharge, overdischarge, overheating, short circuits, and voltage imbalances. Certifications include UL 1642, IEC 62133, CE, RoHS, UN38.3, and MSDS, ensuring compliance with international safety and quality standards.

How does charging and discharging work for a 72V 160Ah lithium golf cart battery?

The battery uses a CC/CV (constant current/constant voltage) charging method with a standard charge current of 30A and maximum continuous discharge current of 160A. Peak discharge can reach 315A for short bursts. Charging time varies from 1 to 5.5 hours depending on current, enabling flexible and efficient recharging.

What are the physical size and weight considerations for installation?

Measuring approximately 960 mm long, 446 mm wide, and 217 mm high, and weighing about 88 kg, this battery fits most standard golf cart compartments. Its metal casing ensures durability while maintaining manageable weight for ease of installation.

How does temperature influence the performance of a 72V 160Ah lithium golf cart battery?

Operating efficiently between -20°C and 65°C for discharge and 0°C to 60°C for charging, the battery maintains stable performance in diverse climates. Extreme temperatures can affect capacity and lifespan, so temperature-controlled charging and storage are recommended.

How do you select the right 72V 160Ah lithium battery for your golf cart?

Selection depends on your golf cart’s voltage requirements, physical space, desired range, and load capacity. Consulting with Lithium-Battery-Manufacturer ensures optimal customization and compatibility for your specific vehicle model.

What maintenance practices maximize lifespan and safety of the battery?

Maintenance is minimal: keep terminals clean, avoid deep discharges, monitor battery health via BMS, and store in cool, dry environments. Unlike lead-acid batteries, no watering or equalizing is required, reducing labor and risk.

How does the Battery Management System (BMS) enhance safety and performance?

The BMS continuously monitors voltage, current, temperature, and state of charge, balancing cells and preventing unsafe conditions such as overcharge, overdischarge, short circuits, and thermal runaway. It enables remote monitoring and predictive maintenance, ensuring safety and longevity.

Battery Specification and Performance Chart

Charging and Temperature Range Chart
